Dry Cabinet 254L

Dry Cabinet 254L

Vysoušecí skříně určené pro skladování MSD součástek (Moisture Sensitive Devices).

Odpovídají normě J-STD-033 (Handling, Packing,. Shipping and Use of. Moisture/Reflow. Sensitive Surface. Mount Devices).

Skříně jsou v ESD provedení.

Jednoduchá obsluha.

Including:

• 1 door - 254 Liters
• 2 shelf as standard (Black paint E.S.D. 103 ►109 Ω)
• Internal dimensions: W598 x D642 x H525mm
• External dimensions: W600 x P672 x H632 mm
• 230V/50Hz - Black color
• Consumption: 55W/h (av erage) 155W/h M ax
• RH Control </= 5 %
• (recommended for MSL classes 4, 5, 6a)
• Digital display
• (Includes alarms on T° & RH%) & RS232 connector
• Humidity display accuracy: ± 3%
• Temperature display accuracy : ±1°C
• Calibration by exchange of display
• Dehumidify ing units (x2) Warranty 2 years
• Structure: 1mm thick carbon steel
• 100% E.S.D. glasses
• Magnetic door closure
• E.S.D. paint 103 ►109 Ω
• Grounding wire 1MΩ (Length 180cm)
• Trackinf soft. T°C-RH% (Humidity Manager V2)
• Complies with IPC/JEDEC J-STD-033-C
• Cabinet warranty: 1 year
• Options:
• Nitrogen flushing unit + Flow Meter
• Flash tower
• Indoor induction light
• Slide shelves
• Full door (specify at the order)
• Data Logger/Reader
• Extended bin system
• Red or Yellow, or Grey
• 4 antistatic wheels (2 with brake)
