Dry Cabinet 1703 L – 6 doors

Code: DC1703-6D

€7 734,57 / pcs €9 358,83 incl. VAT

Professional ESD dry cabinet, 1703 l, 6-door, for storing moisture-sensitive devices (MSL). Humidity control ≤ 5% RH, digital display, metal ESD construction, per IPC/JEDEC J-STD-033-D.

Detailed information

Professional ESD services for companies — consulting, audits, measurements, employee training, and complete ESD workplace implementation according to IEC 61340-5-1.

Description

Product detailed description

Dry Cabinet 1703 L – 6 doors

Professional ESD dry cabinet with 1703 l capacity for storing moisture-sensitive devices (MSD/MSL). Maintains relative humidity ≤ 5% RH and protects electronic components in compliance with IPC/JEDEC J-STD-033-D.

Features

Usable capacity 1703 litres, number of doors: 6, 3 shelves as standard
Humidity control ≤ 5% RH – recommended for MSL classes 4, 5 and 6a
Internal dimensions (W × D × H): 1192 × 682 × 1870 mm
External dimensions (W × D × H): 1200 × 715 × 1985 mm
Digital display, 40,000 temperature and humidity records, software and USB cable included
Humidity accuracy ±3% RH, temperature ±0.2 °C
Dehumidifying units (4×) with 2-year warranty
1 mm metal structure, 100% ESD glass doors
Magnetic door seal with lock and key
ESD paint 10³–10⁹ Ω, 94 cm grounding wire
4 antistatic castors (2 swivel)
Power supply 230 V / 50 Hz, black, power consumption 105 W/h (max. 300 W/h)
Compliant with IPC/JEDEC J-STD-033-D, CE marking
1-year warranty (parts and labour)
