Weller Zero Smog EL Kit Desktop Solder Fume Extractor
Code: FT91012699N
Product detailed description
Weller Zero Smog EL Kit Desktop Solder Fume Extractor
Weller Zero Smog EL Kit 1
Solder fume extraction system Weller Zero Smog EL Kit 1 (item no. FT91012699N) with a flexible extraction arm and funnel nozzle for area-wide fume extraction. Protects workers from harmful fumes from soldering and flux. Suitable for 1 to 2 workstations, the portable unit can be placed under the bench or next to the workstation.
Features
- Extraction for 1 to 2 workstations with a funnel nozzle for wide coverage of the work surface
- Exceptionally large HEPA H13 filter area (2.4 m²) for long filter life
- Granular activated carbon filter for effective filtration of gases and odour
- Separately replaceable M5 class prefilter without needing to replace the main filter
- 4-stage extraction power control
- Filter clogging monitoring and filter alarm for timely replacement
- Exceptionally long service life thanks to a maintenance-free brushless EC turbine
- Compatible with WX and WT nozzles, max. blower vacuum 2,500 Pa
Additional parameters
| Category: | Soldering equipment — soldering stations and tips JBC, Weller, QUICK |
|---|---|
| Supply voltage: | 230 V |
| Power consumption: | 120 VA |
| Max. blower vacuum: | 2,500 Pa |
| Number of workstations: | 1–2 |
| Dimensions (L×W×H): | 335 × 360 × 445 mm |
| Weight: | 8.6 kg |
| Filtration: | HEPA H13 (2.4 m² filter area) + activated carbon |
| Prefilter: | Class M5, separately replaceable without replacing the main filter |
| Compatible nozzle: | WX, WT |
| Power control: | 4-stage |
| ESD safe: | Yes |
