C245

The 0.6 mm conical tip has a straight working geometry for localized contact with the joint. For JBC T245 handles.

The special working face is designed for drag soldering QFP integrated circuits. For JBC T245 handles.

The PLCC Drag shape is intended for drag soldering integrated circuits with matching lead geometry. For JBC T245 handles.

The open forked Chip end is designed for desoldering chip components. Its designated size is 1.9 mm. For JBC T245 handles.

This forked Chip tip is intended for desoldering chip components. Match the working-end shape to the component terminals. For JBC T245 handles.

The open Chip end is intended for desoldering chip components. Match its 3.4 mm size to the specific component package. For JBC T245 handles.

This model provides an open 4.5 mm Chip end for desoldering chip components. For JBC T245 handles.

The fine 0.4 mm conical end is bent away from the tool axis, providing an angled contact approach. For JBC T245 handles.

The 0.3 mm diameter provides a fine conical end for positioning the tip on a small solder pad. For JBC T245 handles.

The straight conical geometry with a 0.4 mm diameter suits joints that require a narrow, unbent end. For JBC T245 handles.

The short bent end approaches the joint at an angle while retaining a fine 0.4 mm tip diameter. For JBC T245 handles.

The straight fine tip has a 0.5 mm end for targeted contact. Check the working profile against the clearance around the joint. For JBC T245 handles.

This special conical tip has an extended tinned surface, distinguishing it from a standard tip with the same 1 mm diameter. For JBC T245 handles.

JBC C245052: heat-staking tip for plastics Ø 4.9 mm. The tip transfers heat to plastic during heat staking. For JBC tools T245.

JBC C245053: heat-staking tip for plastics Ø 3.8 mm. The tip transfers heat to plastic during heat staking. For JBC tools T245.

JBC C245054: heat-staking tip for plastics Ø 6.5 mm. The tip transfers heat to plastic during heat staking. For JBC tools T245.

The 3.5 mm HT bevel combines a wider contact end with geometry designed for efficient heat transfer. For JBC T245 handles.

This straight chisel geometry measures 3 × 1 mm. C245761 is the bent alternative to this model. For JBC T245 handles.

The reduced tinned area is intended especially for touching up solder joints. For JBC T245 handles.

The 2.3 mm spoon face has a visible recess for working with solder. For JBC T245 handles.

This special chisel has extra iron plating. The manufacturer identifies it as particularly suitable for robotic applications. For JBC T245 handles.

JBC C245070E: chisel tip 5 × 1.7 mm. The flat end can contact a solder pad along its edge or across its broader face. For JBC tools T245.

The bridge-shaped end heats two ends of a connector simultaneously during rework. This model is intended for Faston terminals. For JBC T245 handles.

The 2 mm bevel has a reduced tinned area for targeted touch-up work on individual joints. For JBC T245 handles.

The 3 mm conical tip uses HT geometry for joints requiring efficient heat transfer. For JBC T245 handles.

JBC C245109: coating removal tip 4.3 mm. The tip removes coatings during electronics rework. It is not intended for soldering. For JBC tools T245.

JBC C245116: pin and connector tip R 1 mm. The special profile is designed for soldering connector contacts. For JBC tools T245.

JBC C245117: pin and connector tip Ø 1.45 mm. The special profile is designed for soldering connector contacts. For JBC tools T245.

JBC C245118: pin and connector tip 0.4 mm. The special profile is designed for soldering connector contacts. For JBC tools T245.

JBC C245119: PTFE-coated hole-punch tip for plastics Ø 1 mm. The PTFE-coated tip forms holes in plastic by heat. Its working temperature must remain below 200 °C. For JBC tools...

JBC C245121: cutting tip for plastics 13 mm. The heated blade is intended for cutting plastic materials. For JBC tools T245.

JBC C245122: pin and connector tip R 2 mm. The special profile is designed for soldering connector contacts. For JBC tools T245.

JBC C245123: heat-staking tip for plastics 4 × 4 mm. The tip transfers heat to plastic during heat staking. For JBC tools T245.

JBC C245124: heat-staking tip for plastics 4.25 × 2 mm. The tip transfers heat to plastic during heat staking. For JBC tools T245.

The bent working section has a distinctly offset fine end, combining a 0.4 mm diameter with access away from the tool axis. For JBC T245 handles.

JBC C245136: micro stick switch desoldering tip. The shaped tip desolders micro stick switches, for example during mobile device repairs. For JBC tools T245.

JBC C245138: cutting tip for plastics 12 mm. The heated blade is intended for cutting plastic materials. For JBC tools T245.

JBC C245143: double heat-staking tip for plastics Ø 1.8 mm. The twin working ends heat-form two plastic rivets. For JBC tools T245.

This chip-desoldering tip has a special tinned length of 3.5 mm. Its designated Chip size is 2.2 mm. For JBC T245 handles.

JBC C245155E: chisel tip 2.4 × 0.8 mm. The flat end can contact a solder pad along its edge or across its broader face. For JBC tools T245.

JBC C245156E: bevel tip Ø 2.4 mm. The bevel provides a contact face for soldering with the handle held at an angle. For JBC tools T245.

JBC C245157E: knife tip 7.2 × 0.1 mm. The knife profile combines a narrow edge with an elongated soldering face. For JBC tools T245.

JBC C245158E: chisel tip 1.2 × 0.4 mm. The flat end can contact a solder pad along its edge or across its broader face. For JBC tools T245.

JBC C245159E: chisel tip 0.8 × 0.4 mm. The flat end can contact a solder pad along its edge or across its broader face. For JBC tools T245.

JBC C245160E: chisel tip 1.6 × 0.5 mm. The flat end can contact a solder pad along its edge or across its broader face. For JBC tools T245.

JBC C245161E: chisel tip 3.2 × 0.8 mm. The flat end can contact a solder pad along its edge or across its broader face. For JBC tools T245.

The hollow working end has a chrome finish for heat staking plastic rivets. For JBC T245 handles.

The Plastics Inox design is intended for plastic applications and has a cylindrical end measuring 1.7 mm in diameter. For JBC T245 handles.

JBC C245167: thermal hole-punch tip for plastics Ø 2.1 mm. The heated pointed end forms holes in plastic. For JBC tools T245.

JBC C245168: thermal hole-punch tip for plastics Ø 3.1 mm. The heated pointed end forms holes in plastic. For JBC tools T245.
