The 1 × 0.5 mm chisel provides a small flat contact edge with a compact working profile. For JBC T245 handles.
The compact chisel is 1.8 mm wide and 0.5 mm thick, providing a wider contact edge than C245170. For JBC T245 handles.
JBC C245172E: bevel tip Ø 1 mm. The bevel provides a contact face for soldering with the handle held at an angle. For JBC tools T245.
JBC C245175E: bevel tip Ø 1.2 mm. The bevel provides a contact face for soldering with the handle held at an angle. For JBC tools T245.
JBC C245176E: bevel tip Ø 1.5 mm. The bevel provides a contact face for soldering with the handle held at an angle. For JBC tools T245.
JBC C245201: conical tip Ø 0.6 mm. The conical end provides point contact with an individual solder joint. For JBC tools T245, ALE250.
JBC C245215: dual-in-line tip 9.6 × 18 mm. Two opposing contact sides serve components with two rows of leads. For JBC tools T245.
JBC C245220: dual-in-line tip 5.4 × 6 mm. Two opposing contact sides serve components with two rows of leads. For JBC tools T245.
JBC C245221: dual-in-line tip 5.4 × 10 mm. Two opposing contact sides serve components with two rows of leads. For JBC tools T245.
JBC C245222: dual-in-line tip 7.1 × 13 mm. Two opposing contact sides serve components with two rows of leads. For JBC tools T245.
JBC C245223: QFP desoldering tip 8.5 × 8.5 mm. The shaped end desolders QFP and PLCC packages by contact heating their leads. For JBC tools T245.
JBC C245224: QFP desoldering tip 12 × 12 mm. The shaped end desolders QFP and PLCC packages by contact heating their leads. For JBC tools T245.
JBC C245226: dual-in-line tip 15.2 × 29 mm. Two opposing contact sides serve components with two rows of leads. For JBC tools T245.
JBC C245227: QFP desoldering tip 17.5 × 17.5 mm. The shaped end desolders QFP and PLCC packages by contact heating their leads. For JBC tools T245.
JBC C245228: QFP desoldering tip 12.4 × 15 mm. The shaped end desolders QFP and PLCC packages by contact heating their leads. For JBC tools T245.
JBC C245230: conical tip Ø 0.3 mm. The conical end provides point contact with an individual solder joint. For JBC tools T245, ALE250.
JBC C245234: bent conical tip Ø 0.4 mm. The bent end provides angled access to the joint. For JBC tools T245.
The square 17 × 17 mm working end is designed for PLCC sockets with 44 contact positions. For JBC T245 handles.
The special rectangular end is designed for PLCC sockets with 32 contact positions. For JBC T245 handles.
JBC C245250: dual-in-line tip 5.4 × 8 mm. Two opposing contact sides serve components with two rows of leads. For JBC tools T245.
JBC C245256: bevel tip Ø 3.5 mm. The bevel provides a contact face for soldering with the handle held at an angle. For JBC tools T245, ALE250.
The 1.5 mm conical end is bent for angled contact. Allow for the bend when checking clearance around the joint. For JBC T245 handles.
The bent 2 mm conical end uses an HT design, combining angled access with heat-transfer geometry. For JBC T245 handles.
JBC C245261: chisel tip 3 × 1 mm. The flat end can contact a solder pad along its edge or across its broader face. For JBC tools T245.
JBC C245268 – Dual In Line cartridge 5 × 1.5 mm. Special cartridge for fast soldering of male contacts, designated Dual In Line by the manufacturer.
JBC C245301: bevel tip Ø 8.8 mm. The bevel provides a contact face for soldering with the handle held at an angle. For JBC tools T245.
JBC C245303: dual-in-line tip 6.5 × 6 mm. Two opposing contact sides serve components with two rows of leads. For JBC tools T245.
JBC C245304: tunnel tip for DIL 9.6 × 15 mm. Two opposing contact sides serve components with two rows of leads. For JBC tools T245.
JBC C245305: dual-in-line tip 9.6 × 12 mm. Two opposing contact sides serve components with two rows of leads. For JBC tools T245.
JBC C245306: dual-in-line tip 9.6 × 10 mm. Two opposing contact sides serve components with two rows of leads. For JBC tools T245.
JBC C245311: heat-staking tip for plastics 20 × 6 mm. The special working end is intended for thermal processing of plastics. For JBC tools T245.
JBC C245312: heat-staking tip for plastics Ø 3.2 mm. The special working end is intended for thermal processing of plastics. For JBC tools T245.
JBC C245313: heat-staking tip for plastics Ø 4.1 mm. The special working end is intended for thermal processing of plastics. For JBC tools T245.
JBC C245315: QFP desoldering tip 15 × 15 mm. The shaped end desolders QFP and PLCC packages by contact heating their leads. For JBC tools T245.
JBC C245344: QFP desoldering tip 26 × 26 mm. The shaped end desolders QFP and PLCC packages by contact heating their leads. For JBC tools T245.
JBC C245351: QFP desoldering tip 12.3 × 12.3 mm. The shaped end desolders QFP and PLCC packages by contact heating their leads. For JBC tools T245.
JBC C245352: QFP desoldering tip 15.4 × 15.4 mm. The shaped end desolders QFP and PLCC packages by contact heating their leads. For JBC tools T245.
JBC C245354E: bevel tip Ø 3.5 mm. The bevel provides a contact face for soldering with the handle held at an angle. For JBC tools T245.
The 1 mm conical HT design uses geometry optimized for heat transfer during soldering. For JBC T245 handles.
This HT bevel retains a 1.5 mm diameter with geometry optimized for heat transfer. For JBC T245 handles.
This 1.2 × 0.7 mm version uses an HT chisel geometry for thermally demanding soldering work. For JBC T245 handles.
The 2.2 × 1 mm HT chisel transfers heat through a flat working end. For JBC T245 handles.
The bent 3 mm conical end provides a larger contact end for angled access to the joint. For JBC T245 handles.
The bent 4 mm conical tip uses an HT design for thermally demanding joints approached at an angle. For JBC T245 handles.
JBC C245629E: bent conical tip Ø 4 mm. The bent end provides angled access to the joint. For JBC tools T245.
JBC C245651: drag soldering tip 1.25 mm. The forked design is intended for drag soldering through-hole leads. For JBC tools T245.
JBC C245654: drag soldering tip 0.75 mm. The forked design is intended for drag soldering through-hole leads. For JBC tools T245.
JBC C245658: forked Chip tip 2 mm. The forked end is designed for working on chip components. For JBC tools T245.
JBC C245662: round connector tip R 4.5 mm. The rounded recess contacts cylindrical terminals when soldering cables and connectors. For JBC tools T245.
JBC C245667: drag soldering tip 1.25 mm. The forked design is intended for drag soldering through-hole leads. For JBC tools T245.
